material handling equipment from China manufacturer

Payment Terms:	T/T,L/C
Place of Origin:	Shanghai, China (Mainland)

Product Detail

Model No.: AMWP1000

Production Capacity: 1000000

Means of Transport: Land

Delivery Date: 7-30days

high efficient

Standard Configuration -Can bus line intelligent controller -Proportional controller -Charge indicator -Working chronometer -Transport standard forklift hole -Electric circuit fault code display -Low voltage alarm -Emergency descending button -Extended platform -Charge protection -Horn -Tilt protection -Tilt alarm -Driving motor overtemperature protection -Multi-language -4x2 drive -Overload limit -Standard platform -Tube bracket
Model			AMWP6.5-1000
Safe working load		kg	250
Maximum working height		mm	6500
Overall length		mm	1540
Overall width		mm	1200
Overall height		mm	1820
Working platform size		mm	1200X1190
Minimum ground clearance		mm	60
Wheelbase		mm	1290
Min turning radius inner/outer wheel		mm	850/2000
Driving motor			2×24VDC/0.5kw
Lifting motor			24VDC/2kw
Travel Speed	Stowed	km/h	4
	Lifting	km/h	1.1
Lifting/ descending speed		sec	43/35
Accumulator			2×12V/120Ah
Charger			24A/12A
Gradeability		%	25
Max angle		ì	1.5
Rear wheel		mm	250×80
Front wheel		mm	250×80
Overall weight		kg	950
