Electric Aluminium Work Platform AMWP1000 manufacturer from China Cheuklift Co., Ltd.

Payment Terms:	T/T,L/C
Place of Origin:	Shanghai, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: AMWP1000

Production Capacity: 1000000

Means of Transport: Land

Delivery Date: 7-30days

high efficient

Introduce: The product is mainly applied in power, communication, airport, conference and exhibition center, supermarket, factory, station, subway station, etc. It is only for one persons working. CE certified. 1) Powered by DC, self-propelled, has the function of infinitely shift-speeds, controlled by joystick. 2)The driving motor has the automatic braking function. 3) Gradeability: 15-20%. 4) Charge protection: When charged, the product can be operated. 5) The malfunction can be diagnosed and displayed in codes. Emergency down-valve device. 6) Pothole-protection and tilt alarm. Parameters:

Standard Configuration -Can bus line intelligent controller -Proportional controller -Charge indicator -Working chronometer -Transport standard forklift hole -Electric circuit fault code display -Low voltage alarm -Emergency descending button -Charge protection -Horn -Tilt protection -Tilt alarm -Driving motor overtemperature protection -Multi-language -4x2 drive -Overload limit
Optional Configuration
Model No.		AMWP6-1000	AMWP7.5-1000
Max. Platform Height	mm	6000	7500
Max. Machine Height	mm	8000	9500
Min. Platform Height	mm	510
Ground Clearance	mm	50
Lift Rated Capacity	kg	150	125
Platform Extend Capacity		Free Set
Platform Size	mm	7807001150
Platform Extend Length	mm	Free Set
Max. Drive Speed (Platform Stowed)	km/h	4
Max. Drive Speed (Platform Elevated)		1.1
Min. Turning Radius	mm	1350
Max. Travel Grade	%	25
Caster Size	in	8
Driving Wheel Size	mm	d230*80
Driving Motor	v/kw	2*24/0.4-0.5
Lifting Motor	v/kw	2-24
Aneroid Battery	v/Ah	2*12/100
Charger	v/A	12-24
Pothole Protection System	mm	Automechanism
Overall Length	mm	1360
Overall Width	mm	790
Overall Height		1980
Overall Net Weight	kg	850	880
